HOME > Natural Diamond Cutting Tools
Natural Diamond Cutting Tools
Natural Diamond Cutting Tools
Natural Diamond Cutting Tools are employed to precision cutting of non-ferrous materials and non-metallic materials. Depending upon the purpose, mirror or rainbow finish can be achieved at highly stable precision level.
Features of Natural Diamond Cutting Tools
- Due to its high wear resistnace, it can be used for long time.
- High quality surface can be achieved.（0.025μmRa）
- It can be used at high speed cutting.
- The level of finished surface of the workpiece is stable
- It is not suitable for cutting ferrous materials.
Cutting condition of the Natural Diamond Cutting Tools
| Workpiece | Cutting speed（m/min） | Depth of Cut（mm） | Feed（mm/rev） |
|---|---|---|---|
| Aluminium | 150 ～ 1000 | 0.05 ～0.25 | 0.02 ～ 0.1 |
| Copper | 140 ～ 750 | 0.05 ～ 0.25 | 0.02 |
| Bronze・brass | 140 ～ 500 | 0.05 ～ 0.25 | 0.02 ～ 0.1 |
| Hard rubber | 140 ～ 750 | 0.1 ～ 0.7 | 0.1 ～ 0.2 |
| Plastic | 360 ～ 1000 | 0.1 ～ 0.5 | 0.1 ～ 0.2 |
